Disc Type Magnetic Separator

APPLICATION OF 3PC DISC DRY MAGNETIC SEPARATOR, BELT MAGNETIC SEPARATOR:

EMI 3pc Disc Dry Magnetic Separator is a Dry Intensified Magnetic Separator, applicable for separations of ilmenite, rare earth ore, chromite, tungsten and tin ores, limonite, columbium and tantalum ores, ziron, rutile, monazite, andalusite, garnet, kyanite, feldspar, quartz and other minerals with magnetic differences or removal of iron in nonmetallic minerals. 4 varieties of products can be obtained by separation of the device.

STRUCTURE OF 3PC DISC DRY MAGNETIC SEPARATOR, BELT MAGNETIC SEPARATOR

Main device comprised feeding unit, weak magnetic roller, drive part, material conveying apparatus, magnetic disc, electromagnetic system, frame and others. The electric control section consists of components of control, voltage regulation, rectification, instrument and so on. It features compact structure, stable performance, easy installation and convenient operation and maintenance, this disc type dry belt magnetic separator has 3 types: 1 pc disc, 2 pcs disc, and 3 pcs disc. The following structure is showing the 2pcs disc dry magnetic separator. The moisture of the feeding material should be under 1%.

ADVANTAGES OF 3PC DISK DRY MAGNETIC SEPARATOR, BELT MAGNETIC SEPARATOR

Very high magnetic field intensity 16000gauss – 20000gauss
This separator can separate four different minerals in one time.
This separator can get the final concentrate of three to four mineral.
Ta &Nb grade can reach 60% by using this separator.
It’s easy to install, adjust, and operate.
The magnetic intensity of each disc is adjustable from 1000-20000 gauss, could be used for other mineral concentration.
